Bead Dia.

19.5〃—24.5〃

Tire size

9R20—11R24.5,315/80R22.5,12.00R24,385/55R22.5,425/65R22.5,445/65R22.5

Range of tire Dia.(mm)

Φ760—φ1200

Range of belt drum Dia.(mm)

Φ670—φ1200

Range of carcass drum Dia.(mm)

Φ450—φ630

Max. Width of sidewall and inner   liner(mm)

850—1600

Max. Width of sidewall supply(mm)

400

Max. Width of inner line supply(mm)

1050

Outer distance of bead(mm)

460—930

Max. Ply width(mm)

1050

Max. Chafer width(mm)

220

Range of belt width(mm)

52—450

Max. Tread width(mm)

500

Air pressure(Bar)

7—8

Total installed power(kW)

65

Overrall dimension(m)

19*16*3.6
